Dowel Pin

Dowel Pin

Dowel pins and locating pins for jigs, fixtures, tooling plates and assembly stations. Round, tapered, stepped and relieved body versions with vented and spherical options.

Key features

• Precision ground diameters with consistent fit
• Round, stepped, tapered and relieved bodies
• Ball head, flat head and spherical locating versions
• Vented options for fixture speed
• Metric sizes with matching jig bushings

Specification

What to send with your enquiry

• Material
• Surface Finish
• Hardness
• Quantity required

Any one of these is enough to start: the series code, a drawing, or the dimensions you need.

Applications

Used in jigs, fixtures, tooling plates and assembly stations where a part has to be located and released repeatedly.

Sizes shown cover the full series range. Tell us the exact size and quantity and we confirm the drawing before production.

Ordering & quotation

Send the series code, size and quantity you need. We reply with availability, lead time and price the same working day, and ship mixed lines together.
